The single cylinder deadbolt with an enlarged back plate is a perfect match to all designer series Italian collection entry knobs or levers where additional security is required. The design of the deadbolt includes all the important features of a high quality deadbolt while offering matching style and beauty. Each deadbolt comes with long 3 in. strike plate security screws. Thumb turn on the inside unlocks the deadbolt without a key to provide a quick and easy exit in an emergency.
-
1-in throw with hardened steel rod
-
Protective collar
-
Interlocking installation guides
-
Reinforced spring assembly
-
High security strike assembly
Technical Specification Download- Category:
- Entrance Hardware
- Sub-Category:
- Deadbolts
- Product Group:
- Square Deadbolts
- Model:
- 200S
- Function:
- Single Cylinder
- Function Description:
- Deadbolt thrown or retracted by key on the outside or by inside turn unit. Bolt automatically deadlocks when thrown.
- Grade:
- Grade 3
- Finish:
- Black (US19)
- Trim:
- -
- Keyed:
- Yes
- Cylinder:
- Selectable
- Backset:
- 2-3/8" to 2-3/4"
- Cross Bore:
- 2-1/8"
- Edge Bore:
- 1"
- Latch Face:
- 1" x 2-1/4"
- Door Thickness:
- 1-3/8" x 1-3/4"
- Latch:
- -
- Deadbolt Throw:
- -
- Strike:
- -
- Faceplate:
- -
- Fasteners:
- Combination wood/metal screws.
- Case Quantity:
- 10 Pcs
- Case Weight:
- 21 Lbs.
